Industrial Photography Oil and Gas drilling platform

Constructing an offshore drilling platform at sea must be a really difficult task compared to the convenience of buildingit on land. The sheer scale of the project and the size of the components would make this a logistical nightmare.

Here, OGN had booked a session to update their records and get some action shots of their build in progress for future marketing use. Convenient as it might be, constructing in parts and moving 300 ton structures to marry together is still no mean feat.

Preparing pipe surfaces for welding on a platform deck

Checking the lift area is clear from obstructions

In the massive sheds, further parts of the structure are taking shape and getting ready to be moved down to take their place on the growing platform in the yard. View the samples below for various aspects of the construction.


		PausePlayPlayPrev|Next



			Surveyour setting out on the Oil and Gas platform

			Oil and Gas jacket support strut showing joint profile

			Cathodic protection. Welding sacraficial magnesium anodes to a support leg

			Cranes and Riggers on site

			Oil and Gas rig legs and struts ready for assembly

			A high access point provides a view over the site to the sea beyond

			A new platform approaching the Oil and Gas Jacket

			Platform being manouvered under supervision

			Positioning platform

			The platform skid team

			The platform skid team

			Crane lift of platform into pposition

			Crane lift of platform into position

			Checking alignment of platform

			Checking alignment of new platform

			Grinding the metal surfaces prior to fixing the new platform in position

			Aligning the new platform and winching the two parts together

			Removing shackles and slings

			Part of the platform takes shape inside the shed

			Indoor construction of Oil and Gas rig.
